30 September 2026 · DMARC Engine · 33 min read
Hybrid Mail Server Environments: The DMARC Conundrum
Organisations with hybrid mail server environments, comprising both on-premise and cloud-hosted mail servers, face a unique set of challenges when implementing DMARC. The primary issue centres around maintaining alignment between SPF and DKIM records, which is crucial for achieving a satisfactory DMARC pass rate. In a hybrid setup, mail can originate from multiple sources, making it difficult to optimise DMARC records for all possible mail streams.
For instance, consider a company that uses a cloud-based mail service, such as Office 365, for employee email, while also maintaining an on-premise mail server for automated notifications and system alerts. In this scenario, the company must ensure that both the cloud-hosted and on-premise mail servers are correctly configured to authenticate mail using SPF and DKIM.
example.com. IN TXT "v=spf1 include:_spf.example.com ip4:192.0.2.1 -all"
example.com. IN TXT "v=dkim1; k=rsa; p=MIGfMA0GCSqGSIb3DQEBAQUAA4GNADCBiQKBgQC4hxBj6K..."The SPF record includes the IP address of the on-premise mail server, while the DKIM record is configured for the cloud-hosted mail service. However, if the on-premise mail server is not configured to sign mail with a DKIM key that aligns with the domain's DKIM record, mail sent from this server may fail DMARC authentication.
To mitigate this issue, organisations can use a third-party DMARC management service, such as DMARC Engine, to host and manage their DMARC, SPF, and DKIM records. These services often provide tools to simplify the management of multiple mail streams and ensure alignment between SPF and DKIM records. For example, a managed DMARC service can help organisations to identify and categorise mail streams, making it easier to configure DMARC records that optimise authentication rates.
Another challenge in hybrid environments is the management of subdomains. In many cases, subdomains are used to segregate different mail streams, such as marketing or automated notifications. However, if these subdomains are not properly configured with DMARC records, they can become a source of unauthenticated mail, negatively impacting the overall DMARC pass rate.
_subdomain.example.com. IN TXT "v=dmarc1; p=none; pct=100; rua=mailto:aggregate@example.com"To address this issue, organisations should ensure that all subdomains are configured with DMARC records that align with the parent domain's DMARC policy. This can be achieved by using a wildcard DMARC record that applies to all subdomains, or by configuring each subdomain with its own DMARC record.
In addition to these technical challenges, organisations with hybrid mail server environments must also consider the operational aspects of DMARC management. For instance, who is responsible for monitoring and maintaining DMARC records, and how will changes to mail server configurations be coordinated across different teams and departments? To optimise DMARC in a hybrid environment, organisations should establish clear processes and procedures for managing DMARC records, and ensure that all relevant teams are aware of their roles and responsibilities.
Ultimately, the key to successful DMARC implementation in a hybrid mail server environment is careful planning, coordination, and monitoring. By understanding the complexities of their mail streams, and using tools and services to simplify DMARC management, organisations can achieve high DMARC pass rates, and protect their domains from spoofing and phishing attacks. In our experience, a well-planned and well-executed DMARC strategy can significantly reduce the risk of email-based threats, and provide a strong foundation for email security and deliverability.
Identifying and Categorising Mail Streams
To effectively implement DMARC in a hybrid on-premise and cloud-hosted mail server environment, it is crucial to first identify and categorise the various mail streams. This step is often overlooked, leading to a maze of complexities when trying to optimise DMARC settings. In our experience, a thorough understanding of the mail streams is essential to avoid unnecessary headaches down the line.
We have seen cases where senders have multiple on-premise mail servers, each with its own set of users, and also utilise cloud-hosted services such as Office 365 or Google Workspace. In such scenarios, it is vital to identify the sources of email, including automated emails, marketing emails, and user-generated emails. For instance, a company may have its own on-premise Exchange server for employee emails, while also using a cloud-based service like Mailchimp for marketing campaigns.
When categorising mail streams, we recommend starting with the easiest ones to identify, such as marketing emails or automated emails from specific applications. These streams often have distinct characteristics, such as specific sender domains or IP addresses. For example, marketing emails may always come from a specific subdomain, like newsletters.example.com.
# Example of a marketing email stream
{
"source_ip": "192.0.2.1",
"sender": "news@example.com",
"recipient": "user@example.net"
}In contrast, user-generated emails can be more challenging to categorise, as they may originate from various sources, including on-premise mail servers, cloud-hosted services, or even personal devices. To tackle this, we suggest using a combination of factors, such as the sender's domain, email client, or authentication methods like SPF and DKIM.
For example, emails sent from an on-premise Exchange server may have a specific SPF record, while emails sent from a cloud-hosted service like Office 365 may have a different SPF record. By analysing these factors, you can start to build a picture of your various mail streams.
# Example of SPF records for on-premise and cloud-hosted mail servers
# On-premise Exchange server
"v=spf1 ip4:192.0.2.1 include:example.com -all"
# Cloud-hosted Office 365
"v=spf1 include:spf.protection.outlook.com -all"In a hosted or managed setup, the process of identifying and categorising mail streams can be simplified, as the provider often has built-in tools and expertise to handle these complexities. For instance, some providers offer pre-configured DMARC settings and automated reporting, which can help streamline the process. However, it is still essential to have a thorough understanding of your mail streams to ensure accurate configuration and effective DMARC implementation.
Once you have identified and categorised your mail streams, you can start to think about how to optimise your DMARC settings for each stream. This may involve setting up separate DMARC records for different streams, or using a single record with specific policies for each stream. The key is to find a balance between security and deliverability, ensuring that legitimate emails are not blocked or flagged as spam.
In our experience, it is crucial to monitor and analyse your mail streams regularly, as changes in email traffic or new email sources can impact your DMARC settings. By staying on top of these changes, you can ensure that your DMARC implementation remains effective and aligned with your organisation's email ecosystem.
To illustrate this point, consider a scenario where a company introduces a new marketing automation platform, which sends emails from a different IP address or domain. If this new stream is not accounted for in the DMARC settings, it may lead to emails being blocked or flagged as spam, resulting in deliverability issues. By regularly monitoring and analysing mail streams, you can identify such changes and adjust your DMARC settings accordingly.
In short, identifying and categorising mail streams is a critical step in implementing DMARC in a hybrid on-premise and cloud-hosted mail server environment. By understanding the various sources of email and their characteristics, you can optimise your DMARC settings to ensure effective security and deliverability. While hosted or managed setups can simplify the process, it is still essential to have a thorough understanding of your mail streams to achieve accurate configuration and effective DMARC implementation.
On-Premise vs Cloud-Hosted: SPF and DKIM Alignment Challenges
When managing a hybrid mail server environment, comprising both on-premise and cloud-hosted mail servers, one of the primary challenges is ensuring proper alignment of SPF and DKIM records. This is crucial for maintaining a high level of deliverability and preventing spoofing attempts. In our experience, misaligned SPF and DKIM records are a common issue, particularly when organisations have a mix of on-premise and cloud-hosted mail servers.
A key consideration is the fact that on-premise mail servers often have static IP addresses, which can be easily included in SPF records. For example, an organisation with an on-premise mail server may have an SPF record that looks like this:
v=spf1 ip4:192.0.2.1 ip4:192.0.2.2 include:_spf.example.com -allIn contrast, cloud-hosted mail servers often use dynamic IP addresses, which can change frequently. This can make it difficult to maintain accurate SPF records, as the IP addresses may need to be updated regularly. To mitigate this issue, many cloud-hosted mail server providers offer dedicated IP addresses or allow customers to use their own IP addresses. For instance, a cloud-hosted mail server provider may offer a service that allows customers to bring their own IP addresses, which can then be included in the SPF record.
DKIM alignment can also be a challenge in hybrid environments. DKIM uses a public-private key pair to authenticate email messages, and the public key is published in a DNS record. When using a cloud-hosted mail server, the DKIM key may be managed by the provider, which can make it difficult to ensure alignment with on-premise mail servers. To ensure proper DKIM alignment, it is essential to use a consistent selector and key pair across all mail servers. For example, an organisation may use a selector like default and a key pair that is shared across all mail servers, including both on-premise and cloud-hosted servers:
default._domainkey.example.com. IN TXT "v=DKIM1; k=rsa; p=MIGfMA0GCSqGSIb3DQEBAQUAA4GNADCBiQKBgQCqGKukO1De7zhZj6+H0qtjTkVxwTCpvKe4eCZ0FPqri0cb2JZfXJ/DgYSF6vUpwmJG8wVQZKjeGcjDOL5UlsuusFncCzWBQ7RKNUSesmQRMSGkVb1/3j+skZ6UtW+5u09lHNsj6tQ51s1SPrCBkedbNf0Tp0GbMJDyR4e9T04ZZwIDAQAB"In a managed setup, such as the one provided by DMARC Engine, the DKIM key management is often handled automatically, which can simplify the process of ensuring DKIM alignment. However, it is still essential to ensure that the DKIM selector and key pair are consistent across all mail servers.
Another challenge in hybrid environments is the need to balance the level of security with the potential impact on deliverability. For example, using a strict SPF record with a -all policy can help prevent spoofing attempts, but it can also block legitimate email messages if the SPF record is not properly aligned with all mail servers. To mitigate this risk, it is often recommended to use a more permissive SPF record with a ~all policy, which will soft-fail messages that do not align with the SPF record rather than blocking them outright.
In addition to SPF and DKIM alignment, it is also essential to consider the impact of mail server configuration on DMARC alignment. For example, if a mail server is configured to use a different domain or subdomain for email messages, this can affect DMARC alignment. To ensure proper DMARC alignment, it is essential to configure mail servers to use a consistent domain or subdomain for email messages.
To optimise DMARC alignment in hybrid environments, we recommend the following best practices:
- Use a consistent selector and key pair for DKIM across all mail servers
- Use a dedicated IP address or bring your own IP address for cloud-hosted mail servers
- Use a permissive SPF record with a
~allpolicy to balance security with deliverability - Configure mail servers to use a consistent domain or subdomain for email messages
- Regularly monitor DMARC aggregate reports to identify alignment issues and make adjustments as needed
By following these best practices and carefully managing SPF and DKIM alignment, organisations can help ensure a high level of deliverability and prevent spoofing attempts in hybrid mail server environments.
Implementing DMARC: A Step-by-Step Guide for Hybrid Environments
Implementing DMARC in a hybrid environment, where mail servers are split between on-premise and cloud-hosted solutions, requires careful planning and consideration of the unique challenges posed by this setup. The primary goal is to ensure that all mail streams, regardless of their origin, are properly authenticated and aligned with the domain's DMARC policy. This involves a series of steps that help in setting up DMARC, SPF, and DKIM in a way that optimises deliverability while minimising the risk of spam and phishing attacks.
First, it is essential to identify all the mail streams that are sending emails on behalf of the domain. This includes not just the obvious on-premise mail servers and cloud-hosted services but also any third-party services that may be sending emails, such as marketing automation platforms or customer support software. For each of these streams, the next step is to determine if they are already set up with SPF and DKIM. If not, these need to be configured.
For SPF, this means adding a TXT record to the domain's DNS that lists all the IP addresses of the mail servers that are authorised to send emails on behalf of the domain. For example, if a company has an on-premise mail server with the IP address 192.0.2.1 and uses a cloud-hosted service with the IP address 198.51.100.1, the SPF record might look like this:
"v=spf1 ip4:192.0.2.1 include:cloudservice.com -all"This record authorises both the on-premise server and the cloud service to send emails, while the -all directive at the end specifies that emails from any other IP addresses should be rejected.
For DKIM, the process involves generating a public/private key pair and then configuring the mail servers to sign outgoing emails with the private key. The public key is then published in a TXT record in the domain's DNS, allowing receiving mail servers to verify the signature. For instance, if the domain example.com has a DKIM key with the selector mail, the DKIM record might look like this:
"mail._domainkey.example.com. 3600 IN TXT \"v=DKIM1; k=rsa; p=MIGfMA0GCSqGSIb3DQEBAQUAA4GNADCBiQKBgQC+ycg5L3vMMqj5m3K1dI4H+VbAnZ7wHjnupJgJXhj3rwxc+6wzG9jJ4M7JY8x3m/6FLz2FvQ9Wx6VQ6PFOVQ6L9fI0L4j0g1S0QZ6T7wQ7x3m\""Once SPF and DKIM are set up for all mail streams, the next step is to implement DMARC. This involves adding a TXT record to the domain's DNS that specifies the DMARC policy. For example, a domain might start with a monitoring-only policy to gather data on email authentication before moving to a policy that rejects or quarantines unauthenticated emails:
"_dmarc.example.com. 3600 IN TXT \"v=DMARC1; p=none; pct=100; rua=mailto:dmarc@example.com; ruf=mailto:dmarc@example.com; fo=1\""This record specifies that the domain is using DMARC version 1, with a policy of none (meaning no action is taken on unauthenticated emails), and requests aggregate reports (rua) and failure reports (ruf) to be sent to the specified email address.
A critical aspect of implementing DMARC in a hybrid environment is ensuring alignment between the domain's DMARC policy and the SPF/DKIM configurations of all mail streams. Alignment means that the domain in the From header of an email matches the domain in the SPF or DKIM authentication. For SPF, this is known as domain alignment, and for DKIM, it is known as organisational domain alignment. Ensuring alignment is crucial because DMARC will only pass if at least one of SPF or DKIM aligns with the domain's DMARC policy.
In a hosted or managed setup, such as the one provided by DMARC Engine, the process of setting up and managing DMARC, SPF, and DKIM is significantly simplified. These services often provide automated tools for generating and publishing the necessary DNS records, as well as dashboards for monitoring DMARC reports and adjusting policies. For instance, DMARC Engine can help in identifying all the mail streams sending emails on behalf of a domain, generate the necessary SPF and DKIM records, and provide detailed analytics on DMARC report data to help in optimising the domain's DMARC policy.
However, even with the support of a managed service, careful planning and monitoring are still required. This includes regularly reviewing DMARC reports to identify any authentication issues or unauthorised senders, and adjusting the DMARC policy as necessary to balance deliverability with the need to protect against spam and phishing. It also involves keeping track of changes in the mail streams, such as the addition of new cloud services or the retirement of old on-premise servers, to ensure that the SPF and DKIM configurations remain up-to-date.
In short, implementing DMARC in a hybrid environment requires a meticulous approach to ensure that all mail streams are properly authenticated and aligned with the domain's DMARC policy. By carefully setting up SPF and DKIM for each mail stream, implementing a DMARC policy, and regularly monitoring and adjusting this policy based on DMARC reports, senders can significantly reduce the risk of their emails being blocked or marked as spam, while also protecting their domain against phishing and spam attacks. Whether managed through a hosted service or in-house, the key to successful DMARC implementation in a hybrid environment is ongoing vigilance and a deep understanding of the complex interactions between DMARC, SPF, and DKIM.
Aggregate Report Analysis: Uncovering Hidden Issues
When managing DMARC for hybrid on-premise and cloud-hosted mail servers, aggregate report analysis is a critical component of maintaining a robust email authentication posture. These reports, typically received from recipient mail servers, provide valuable insights into how your emails are being handled, helping you identify potential issues that could lead to delivery problems. At DMARC Engine, we process thousands of these reports daily, and our experience has shown that there's more to aggregate report analysis than just checking for authentication failures.
One of the most common challenges senders face is deciphering the sheer volume of data contained within these reports. A typical aggregate report might look something like this:
<?xml version="1.0" encoding="UTF-8" ?>
<feedback>
<version>1.0</version>
<report_metadata>
<org_name>example.com</org_name>
<email>abuse@example.com</email>
<extra_contact_info>https://example.com/dmarc</extra_contact_info>
<report_id>1234567890</report_id>
<date_range>
<begin>1643723400</begin>
<end>1646315200</end>
</date_range>
</report_metadata>
<policy_published>
<domain>example.com</domain>
<adkim>r</adkim>
<aspf>r</aspf>
<p>reject</p>
<sp>reject</sp>
<pct>100</pct>
</policy_published>
<record>
<row>
<source_ip>192.0.2.1</source_ip>
<count>10</count>
<policy_evaluated>
<disposition>none</disposition>
<dkim>pass</dkim>
<spf>pass</spf>
</policy_evaluated>
</row>
<row>
<source_ip>198.51.100.1</source_ip>
<count>5</count>
<policy_evaluated>
<disposition>none</disposition>
<dkim>fail</dkim>
<spf>fail</spf>
</policy_evaluated>
</row>
</record>
</feedback>In this example, we see a report from a recipient domain, detailing the authentication results for emails received from example.com. The record section lists individual IP addresses that sent emails, along with the number of emails sent (count), and the authentication results for DKIM and SPF.
A key aspect of aggregate report analysis is identifying trends and anomalies. For instance, if a particular IP address consistently shows authentication failures, it may indicate a misconfiguration or an unauthorized sender. In a hybrid environment, this could mean that either your on-premise or cloud-hosted mail servers are not properly set up for DMARC, SPF, or DKIM.
Another crucial aspect is understanding the impact of your DMARC policy on email delivery. If your policy is set to reject, emails that fail DMARC checks will be rejected by recipient mail servers. This can lead to legitimate emails being blocked if your SPF or DKIM records are not properly aligned or if there are issues with your mail server configurations. In our experience, it's essential to monitor these reports closely when implementing or adjusting DMARC policies to catch any unintended consequences.
The policy_published section of the report provides insight into the DMARC policy that was applied to the emails. Here, adkim=r and aspf=r indicate that the domain owner has specified a relaxed alignment policy for both DKIM and SPF, meaning that the domain or subdomain in the From header does not need to match the domain or subdomain in the DKIM signature or SPF check exactly, but rather can be a subdomain or the same organisational domain. The p and sp tags specify the policy for the domain and subdomains, respectively, with reject indicating that emails failing DMARC checks should be rejected.
When analysing aggregate reports, it's also important to consider the reporting frequency and the volume of emails. Reports are typically sent once a day, but this can vary depending on the recipient domain's policy and the volume of emails exchanged. In a hosted or managed setup, such as what DMARC Engine provides, these reports are often collected and analysed centrally, providing a more comprehensive view of email authentication health across all recipient domains.
To optimise your DMARC setup based on aggregate report analysis, we recommend starting with a monitoring policy (p=none) to gather data on email authentication without affecting delivery. Once you've identified and addressed any issues, you can move towards a more restrictive policy, such as quarantine or reject, to better protect your domain from phishing attacks. It's also crucial to ensure that your SPF and DKIM records are correctly set up and aligned with your DMARC policy to avoid unintended email blocking.
In hybrid environments, where both on-premise and cloud-hosted mail servers are used, aggregate report analysis becomes even more complex. You need to ensure that all mail streams, regardless of their origin, are properly authenticated and aligned with your DMARC policy. This often involves careful management of SPF and DKIM records to include all legitimate sending sources. For example, if you're using a cloud-based marketing platform, you'll need to include its IP addresses in your SPF record and potentially set up custom DKIM selectors for its use.
In conclusion to this section, effective aggregate report analysis is key to maintaining a healthy DMARC posture, especially in hybrid mail server environments. By closely monitoring these reports, senders can identify and rectify authentication issues, optimise their DMARC policies, and ensure that their emails are delivered reliably to recipient inboxes. At DMARC Engine, our experience with managing DMARC for customers has shown us the importance of detailed report analysis in preventing delivery issues and protecting domain reputation.
Record Examples and Best Practices for Hybrid Setups
When managing DMARC for hybrid environments, the key to success lies in the careful organisation of DNS records, particularly for SPF and DKIM. A well-structured approach to these records can significantly optimise deliverability and reduce the complexity associated with hybrid mail server setups.
For SPF records, the primary challenge in hybrid environments is ensuring that all sending sources, whether on-premise or cloud-hosted, are accurately represented. This often involves including multiple IP addresses and domains within a single SPF record. For example, consider a company that uses both an on-premise mail server with the IP address 192.0.2.1 and a cloud-hosted service like Mailchimp, which has its own set of IPs. The SPF record might look something like this:
"v=spf1 ip4:192.0.2.1 include:_spf.mailchimp.com -all"This record specifies the on-premise IP address and includes Mailchimp's SPF record to cover emails sent through their service. However, it's crucial to keep the SPF record concise and under the 255-character limit imposed by DNS standards. Exceeding this limit can lead to record truncation, resulting in SPF failures for some senders.
In contrast, DKIM records are more about the domain and selector alignment. For hybrid setups, it's essential to ensure that both on-premise and cloud-hosted mail servers can sign emails with a domain-aligned DKIM signature. This might involve setting up multiple DKIM selectors for different mail streams. For instance, a company might use selector1 for their on-premise server and selector2 for their cloud-hosted emails. The DKIM record for selector1 could be:
"selector1._domainkey.example.com. IN TXT \"v=DKIM1; k=rsa; p=MIGfMA0GCSqGSIb3DQEBAQUAA4GNADCBiQKBgQC+yt2wWjwJqH1+6mJQ9ZsXBVeJ5EaQzNNz4nB+6X8Y9z5M9aoXy1Yj9mU6ohUvrT6j2+6F5Ggk3V1Hj7sYQ8RrK5g9S9Q3V8W\""And for selector2, it could be similarly defined but with a different public key.
When implementing DMARC, the policy record is where you define how receivers should handle emails that fail SPF and/or DKIM checks. For hybrid environments, starting with a monitoring policy (p=none) is advisable to gauge the impact on your email streams without affecting deliverability. An example DMARC record might look like this:
"_dmarc.example.com. IN TXT \"v=DMARC1; p=none; pct=100; rua=mailto:aggrep@example.com; ruf=mailto:forensics@example.com; fo=1\""This record sets up DMARC with a monitoring policy, requesting aggregate reports to aggrep@example.com and forensic reports to forensics@example.com, with a full feedback option (fo=1) for maximum insight into email authentication issues.
In managed or hosted setups, such as those provided by DMARC Engine, the colour of the dashboard can quickly indicate the health of your DMARC implementation, with green typically signifying a well-aligned and secure setup, and red highlighting areas that require immediate attention. These tools also automate the process of generating and updating SPF and DKIM records, which can be particularly beneficial for hybrid environments where manual management can become cumbersome and error-prone.
A common mistake in hybrid setups is not accounting for all mail streams. This includes not just primary email services but also automated emails from servers, marketing emails sent via third-party services, and even emails generated by applications. Each of these streams needs to be identified, categorised, and appropriately included in SPF and DKIM records to ensure comprehensive coverage and to prevent unauthenticated emails from being blocked by receivers.
To optimise DMARC for hybrid mail servers, it's essential to regularly review and update DNS records. This involves monitoring aggregate reports for signs of authentication issues, such as emails failing SPF or DKIM checks, and adjusting the records accordingly. For instance, if a report indicates that emails from a specific IP are failing SPF checks, that IP should be added to the SPF record. Similarly, if DKIM validation fails for emails from a particular selector, the DKIM record for that selector may need to be updated or the signing process may need to be adjusted on the mail server.
In dynamic hybrid environments, where mail servers and services are frequently added or removed, maintaining an up-to-date and accurate set of DNS records can be challenging. Implementing a systematic approach to record management, possibly through automation, and regularly analysing DMARC reports can help centre the focus on email deliverability and security, ensuring that the organisation's email streams remain authentic and trustworthy to receivers.
Ultimately, the success of DMARC in hybrid setups hinges on meticulous record management, comprehensive mail stream coverage, and ongoing monitoring and analysis. By understanding the intricacies of SPF, DKIM, and DMARC records and how they interact within hybrid environments, organisations can better navigate the complexities of email authentication, thereby protecting their domain reputation and ensuring the deliverability of their emails.
Troubleshooting Common DMARC Issues in Mixed Environments
When operating in a hybrid environment with both on-premise and cloud-hosted mail servers, troubleshooting DMARC issues can become increasingly complex due to the variety of potential misconfigurations and the sheer volume of mail streams to monitor. A common issue we encounter is the misalignment of SPF and DKIM records, which can lead to DMARC failures. For instance, if a company uses a cloud-based service for marketing emails but hosts its own mail server on-premise for transactional emails, ensuring that both the marketing and transactional emails are correctly authenticated can be a challenge.
To illustrate this, consider a scenario where a company, let's call it Example Ltd, has a DMARC record set to quarantine policy, aiming to filter out emails that fail DMARC checks. Their DMARC record might look something like this:
_dmarc.example.com. IN TXT "v=DMARC1; p=quarantine; pct=100; rua=mailto:aggregatereports@example.com; ruf=mailto:forensicreports@example.com; fo=1"However, if their cloud-hosted marketing service uses a different domain for its DKIM signature, and this domain is not included in the SPF record of example.com, emails sent through this service might fail DMARC checks, even though they are legitimate. This can happen if the SPF record for example.com does not include the IP addresses of the cloud service, or if the DKIM key used by the cloud service is not aligned with the domain example.com.
Another issue arises when dealing with subdomains. In a hybrid setup, it's not uncommon for different subdomains to be managed by different teams or even different companies, each with their own mail servers and authentication setups. Ensuring that DMARC, SPF, and DKIM are correctly configured across all subdomains can be daunting. For example, if example.com has a subdomain blog.example.com that is hosted on a completely different platform, any email sent from blog.example.com needs to have its own set of DMARC, SPF, and DKIM records that are correctly configured to avoid authentication failures.
In our experience, one of the most overlooked aspects of DMARC in hybrid environments is the alignment of DKIM selectors. DKIM selectors are used to identify the DKIM key used for signing emails. If a company uses multiple mail servers or services, each might use a different DKIM selector. For DMARC to pass, the domain used in the DKIM signature must align with the domain in the From header of the email. This can become complex in hybrid environments where different mail streams might use different DKIM selectors.
For instance, if Example Ltd uses a DKIM selector named selector1 for its on-premise mail server and another named selector2 for its cloud-hosted marketing service, both selectors need to be included in the DMARC record, and the corresponding public keys need to be published in DNS. The DKIM public key record for selector1 might look like this:
selector1._domainkey.example.com. IN TXT "v=DKIM1; k=rsa; p=MIGfMA0GCSqGSIb3DQEBAQUAA4GNADCBiQKBgQC+ycg5z1h7MkEz/pu0mJ1z0xYPmKz5mH7V9zxu9rZg4vU5eK3G8t3NWu9T6nX1O4i8HwYb0n6zV4lRc7v0P0xVZ4jyUfG4iQIDAQAB"And similarly for selector2.
To troubleshoot these issues effectively, it's crucial to monitor DMARC aggregate reports closely. These reports provide insights into which emails are failing DMARC checks and why. By analysing these reports, senders can identify misconfigurations or missing authentication records. For example, if a report shows that emails sent from a particular subdomain are failing DMARC due to SPF alignment issues, the sender can then update the SPF record for that subdomain to include the missing IP addresses.
In a managed or hosted setup, such as the one provided by DMARC Engine, troubleshooting is somewhat simplified due to the centralised management of DMARC, SPF, and DKIM records. These services often provide tools for monitoring and analysing DMARC reports, making it easier to identify and fix issues. Also, they can offer guidance on best practices for configuring DMARC in hybrid environments, which can significantly reduce the complexity and risk of misconfiguration.
Ultimately, the key to successfully troubleshooting DMARC issues in mixed environments is a combination of careful planning, meticulous record-keeping, and ongoing monitoring of DMARC reports. By understanding the specific challenges posed by hybrid mail server environments and taking a proactive approach to managing DMARC, SPF, and DKIM, senders can optimise their email authentication setup to ensure reliable delivery and protect their domain from spoofing. This involves not just setting up the records correctly but also continuously reviewing and updating them as the email infrastructure evolves. With the right approach, senders can navigate the complexities of DMARC in hybrid environments and improve the deliverability and security of their emails.
Optimising DMARC for Hybrid Mail Servers: Trade-Offs and Considerations
When managing DMARC for hybrid mail servers, the centre of attention is often on aligning SPF and DKIM records to achieve optimal deliverability. However, this is only the tip of the iceberg. In our experience, the real challenge lies in optimising these records to cater to the diverse mail streams emanating from both on-premise and cloud-hosted servers.
A common trade-off is between security and deliverability. For instance, setting a DMARC policy to quarantine or reject can significantly reduce the risk of spoofing, but it may also lead to legitimate emails being blocked if the SPF or DKIM records are not perfectly aligned.
To mitigate this risk, we recommend a gradual rollout of DMARC policies, starting with a none policy to monitor and analyse aggregate reports. This allows senders to identify potential issues and optimise their records before moving to a more restrictive policy.
For example, consider a company with both on-premise and cloud-hosted mail servers, using a DMARC record like this:
_dmarc.example.com. IN TXT "v=DMARC1; p=none; pct=100; rua=mailto:dmarc@example.com; ruf=mailto:dmarc@example.com; fo=1"In this example, the p=none policy indicates that the sender is monitoring aggregate reports without enforcing any specific policy. The pct=100 tag ensures that all messages are subject to DMARC checks, and the rua and ruf tags specify the email addresses for receiving aggregate and failure reports, respectively.
As the sender gains more insight into their mail streams and potential issues, they can adjust the DMARC policy to quarantine or reject, and fine-tune the pct tag to control the percentage of messages subject to the policy.
Another crucial consideration is the management of subdomains. In hybrid environments, it is not uncommon for subdomains to be used for specific mail streams or applications. To avoid unintended consequences, such as blocking legitimate emails, it is essential to implement DMARC records for each subdomain and ensure they are properly aligned with the parent domain.
For instance, if a company uses the subdomain mail.example.com for their on-premise mail server and cloud.example.com for their cloud-hosted server, they should implement separate DMARC records for each subdomain, like this:
_dmarc.mail.example.com. IN TXT "v=DMARC1; p=none; pct=100; rua=mailto:dmarc@example.com; ruf=mailto:dmarc@example.com; fo=1"
_dmarc.cloud.example.com. IN TXT "v=DMARC1; p=none; pct=100; rua=mailto:dmarc@example.com; ruf=mailto:dmarc@example.com; fo=1"In a hosted or managed setup, the centre of attention shifts towards configuring the DMARC records according to the provider's specifications. For example, some providers may require a specific format for the DMARC record or may offer a web-based interface for configuring DMARC policies.
In our experience, the colour of the DMARC record, in terms of its impact on deliverability, can vary significantly depending on the provider and the specific configuration. Therefore, it is crucial to carefully review the provider's documentation and ensure that the DMARC records are properly configured to avoid any issues.
To optimise DMARC for hybrid mail servers, senders should also focus on aligning their SPF records to include all IP addresses and domains used for sending emails. This can be a complex task, especially in environments with multiple mail servers and applications.
A practical approach is to use a combination of SPF records, including include mechanisms, to simplify the management of IP addresses and domains. For example:
example.com. IN TXT "v=spf1 include:_spf.example.com include:cloud.example.com -all"In this example, the SPF record for the parent domain example.com includes the _spf.example.com and cloud.example.com domains, which can be used to manage specific IP addresses and mail streams.
The key to successful DMARC optimisation is continuous monitoring and analysis of aggregate reports. By regularly reviewing these reports, senders can identify potential issues, optimise their DMARC records, and improve the overall deliverability of their emails.
In our experience, the most common issues that arise in hybrid environments are related to misaligned SPF and DKIM records, or incorrect DMARC policies. By carefully reviewing aggregate reports and making adjustments as needed, senders can avoid these issues and ensure optimal deliverability for their emails.
In short, optimising DMARC for hybrid mail servers requires a deep understanding of the trade-offs between security and deliverability, as well as the complexities of managing SPF and DKIM records in diverse mail streams. By taking a gradual and informed approach to DMARC implementation, and continuously monitoring and analysing aggregate reports, senders can ensure the best possible deliverability for their emails.
To achieve this, we recommend that senders organise their DMARC records in a logical and structured manner, using a combination of SPF and DKIM records to simplify the management of IP addresses and domains. By doing so, senders can optimise their DMARC configuration, reduce the risk of spoofing, and improve the overall deliverability of their emails.
Monitoring and Maintaining DMARC in Dynamic Hybrid Environments
Monitoring DMARC in hybrid environments is a complex task that requires careful consideration of various factors, including the dynamic nature of cloud-hosted and on-premise mail servers. As a senior email-deliverability engineer, I have seen firsthand the challenges that come with managing DMARC in such environments. One of the key issues is the need to constantly monitor and update DMARC records to ensure they remain aligned with the organisation's mail streams.
For instance, when a new cloud-hosted service is introduced, it is essential to update the SPF record to include the new service's IP addresses. Failure to do so can result in emails being flagged as spam or rejected by receivers. A typical SPF record for a hybrid environment might look like this:
v=spf1 include:_spf.example.com include:mail.zendesk.com -allIn this example, the record includes the organisation's on-premise mail server (_spf.example.com) and a cloud-hosted service (mail.zendesk.com). However, if the cloud-hosted service changes its IP addresses, the SPF record must be updated accordingly to prevent delivery issues.
Another critical aspect of monitoring DMARC in hybrid environments is analysing aggregate reports. These reports provide valuable insights into email authentication issues, such as SPF and DKIM failures. By regularly reviewing these reports, organisations can identify potential issues before they become major problems. For example, an aggregate report might show a high number of SPF failures from a specific IP address, indicating that the SPF record needs to be updated to include that address.
To optimise DMARC monitoring in hybrid environments, I recommend implementing a centralised monitoring system that can collect and analyse data from both on-premise and cloud-hosted mail servers. This can be achieved using a hosted or managed DMARC solution, such as DMARC Engine, which provides a single centre of control for managing DMARC records and monitoring email authentication issues.
In addition to monitoring DMARC records and aggregate reports, it is essential to maintain alignment between SPF and DKIM records. This can be a challenge in hybrid environments, where mail streams may originate from different sources. To ensure alignment, organisations should implement a consistent naming convention for their SPF and DKIM records. For example, the DKIM record for the example.com domain might look like this:
default._domainkey.example.com. IN TXT "v=DKIM1; k=rsa; p=MIGfMA0GCSqGSIb3DQEBAQUAA4GNADCBiQKBgQCq3gHtq6dUdnPJeKkKfrAN2FzXL4JVFGBSJ1nF8nFk4Q6cQYjN7K4k4K4K4K4K4K4K7nF8nFk4Q6cQYjN7K4k4K4K4K7nF8nFk4Q6cQ"In this example, the DKIM record uses a consistent naming convention (default._domainkey.example.com) that matches the SPF record.
To further optimise DMARC maintenance in hybrid environments, organisations should consider implementing automation tools to streamline the process of updating DMARC records and monitoring email authentication issues. For example, a script can be used to automatically update SPF records when new cloud-hosted services are introduced. Similarly, a monitoring tool can be used to alert administrators to potential issues, such as SPF or DKIM failures, allowing them to take prompt action to resolve the issue.
In terms of trade-offs, organisations must balance the need for strict DMARC policies with the potential impact on email deliverability. For example, implementing a strict DMARC policy (p=reject) can help prevent spam and phishing attacks, but it may also block legitimate emails if the SPF or DKIM records are not properly aligned. To mitigate this risk, organisations can implement a more relaxed DMARC policy (p=quarantine) that allows emails to be delivered to the spam folder instead of being rejected outright.
In conclusion to this section, monitoring and maintaining DMARC in dynamic hybrid environments requires careful consideration of various factors, including the need to constantly update DMARC records, analyse aggregate reports, and maintain alignment between SPF and DKIM records. By implementing a centralised monitoring system, automation tools, and a consistent naming convention, organisations can optimise their DMARC setup and improve email deliverability. However, this is not a conclusion but a practical consideration so let us centre on the practical application of these principles in real-world scenarios to ensure the colour of your organisation's email deliverability remains healthy and optimised for the long term.
